Puntos positivos
- Clase de protección IP65
- Tensión de alimentación 24 V
- Salida 0-10 V CC
- Tipo de canal
Sensor de CO₂ para unidades de tratamiento de aire con salida 0-10V - SEN CO2 02
El SEN CO2 02 es un sensor de CO₂ preciso para unidades de tratamiento de aire, diseñado para el control de flujo volumétrico basado en demanda. Este sensor utiliza tecnología de doble haz infrarrojo estable (dual beam), garantizando una larga vida útil y mediciones fiables. El sensor de CO₂ es adecuado para instalación en conductos y cuenta con una carcasa robusta con grado de protección IP65. La medición se presenta mediante una señal de salida de 0–10 V DC, que registra el nivel de CO₂ en un rango de 0 a 2000 ppm.
| Marca | Ruck ventilatoren GmbH |
| Categoría | Sensores |
| GTIN | 4061199041294 |
| Número de artículo del fabricante | SEN CO2 02 |
| Número de artículo | 65168750 |
Especificaciones
| Código de categoría | 121 |
| Scope of application | Duct |
| With mounting material | Sí |
| Suitable for wall mounting | No |
| Suitable for ceiling mounting | No |
| Suitable for duct mounting | Sí |
| Suitable for tube mounting | Sí |
| Suitable for air | Sí |
| Suitable for liquids | No |
| Suitable for gases | Sí |
| With housing | Sí |
| Cover attachment | Screwed |
| Sensor element inside housing | Sí |
| Sensor element outside housing | No |
| Fixed cable to sensor | No |
| Technology | NDIR |
| Active temperature measurement | No |
| Passive temperature measurement | No |
| Average temperature measuring | No |
| Number of measuring points | 1 |
| Measurement of CO2 | Sí |
| Measurement of VOC | No |
| Measurement of relative air humidity | No |
| Measurement of absolute air humidity | No |
| Enthalpy measurement | No |
| Measurement of dewpoint | No |
| Particulate matter measurement (PM) | No |
| Number of measuring ranges | 1 |
| Offset setting possible | Sí |
| Trend representation | No |
| Error registration possible | No |
| Sensor type | Other |
| Tolerance | 3 % |
| Potentiometer with adjustment knob | No |
| Supporting protocol for BACnet | No |
| Supporting protocol for Modbus | No |
| Supporting protocol for MP (multi point) | No |
| Supporting protocol for KNX | No |
| LoRa technology | No |
| NFC (Near Field Communication) | No |
| Bluetooth | No |
| Wi-Fi-compatible | No |
| Standby push button | No |
| Wireless | No |
| With display | No |
| Type of power supply | Power cord |
| Type of electric connection | Screw connection |
| With reverse polarity protection | Sí |
| Number of output signals | 1 |
| Number of output ranges 0 V ... 10 V | 1 |
| Max. ambient humidity (non-condensing) | 95 % |
| Explosion-proof | No |
| Degree of protection (IP) | IP65 |
| Housing height | 100 mm |
| Housing width | 200 mm |
| Housing depth | 300 mm |
| Housing colour | White |
| Compatible with Apple HomeKit | No |
| Compatible with Google Assistant | No |
| Compatible with Amazon Alexa | No |
| IFTTT support available | No |
